操作質量

3670kg

最大車速

20km/h

額定斗容

0.65m3

裝載機質量

1500kg

Main transmission type

Spiral gear, first stage deceleration

最大牽引力

25kN

TYRE

最大挖掘力

25kN

Type specification

11.00-16

最大爬坡度

30%

Optional

12.0-16.5; 14-17.5

最大卸載高度

2645mm

STEERING SYSTEM

卸載距離

976mm

Type

Articulated load-sensing hydraulic steering system

Overall

尺寸(L*W*H)

4709*1626*2645mm

Steering angle

32°

發動機

Min. turning radius

4283mm

型號

A498BT1

HYDRAULIC SYSTEM

T種類

Inline, direct injection, water cooling

System working pressure

28MPa

額定功率

36.8kW

Lifting time

4.5s

額定轉速

2400r/min

Total time

10s

操作

Cummins B3.3

BRAKE SYSTEM

額定功率

45kW

Service brake

Air-over-hydraulic shoe-type

傳動系統

Parking brake

Manual disc brake type

液力變矩器

Single-stage three-element hydraulic torque converter

FILL CAPACITY

變速箱類型

Axis-fixed, double reduction

Fuel

51L

檔位

2 forward shift, 2 reverse shift

Hydraulic oil

68.6L
